RF27DM71S4詳細信息

prevnext

RF27DM71S4

訂購熱線：13360667204

詳細信息

關鍵詞：3KW立式電機減速器一體機_RF27DM71S4_RF27DT71S4

RF27DM71S4減速機電機參數：

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
RF27DM71S4	84.78	0.25KW	15.0rpm	156N.m	15.5kg	4100N	0.85
RF27DM71S4	74.11	0.25KW	18.0rpm	136N.m	15.5kg	4210N	0.95
RF27DM71S4	69.47	0.25KW	19.0rpm	128N.m	15.5kg	4240N	1.00
RF27DM71S4	61.30	0.25KW	21.0rpm	113N.m	15.5kg	4180N	1.15
RF27DM71S4	55.87	0.25KW	23.0rpm	103N.m	15.5kg	4090N	1.25
RF27DM71S4	48.17	0.25KW	27.0rpm	88N.m	15.5kg	3940N	1.45
RF27DM71S4	44.90	0.25KW	29.0rpm	82N.m	15.5kg	3870N	1.60
RF27DM71S4	39.25	0.25KW	33.0rpm	72N.m	15.5kg	3730N	1.80
RF27DM71S4	36.79	0.25KW	35.0rpm	68N.m	15.5kg	3660N	1.90
RF27DM71S4	32.47	0.25KW	40.0rpm	60N.m	15.5kg	3540N	2.20
RF27DM71S4	28.78	0.25KW	45.0rpm	53N.m	15.5kg	3420N	2.50
RF27DM71S4	24.47	0.25KW	53.0rpm	45N.m	15.5kg	3270N	2.90
RF27DM71S4	28.37	0.25KW	46.0rpm	52N.m	15.5kg	3410N	2.50
RF27DM71S4	26.09	0.25KW	50.0rpm	48N.m	15.5kg	3330N	2.70
RF27DM71S4	22.32	0.25KW	58.0rpm	41N.m	15.5kg	3180N	3.20
RF27DM71S4	19.35	0.25KW	67.0rpm	36N.m	15.5kg	3050N	3.70
RF27DM71S4	18.08	0.25KW	72.0rpm	33N.m	15.5kg	2990N	3.90
RF27DM71S4	15.63	0.25KW	83.0rpm	29N.m	15.5kg	2860N	4.50
RF27DM71S4	13.28	0.25KW	98.0rpm	24N.m	15.5kg	2730N	5.30
RF27DM71S4	11.86	0.25KW	110rpm	22N.m	15.5kg	2630N	5.90
RF27DM71S4	10.13	0.25KW	128rpm	19N.m	15.5kg	2510N	6.60
RF27DM71S4	9.41	0.25KW	138rpm	17N.m	15.5kg	2440N	7.00
RF27DM71S4	8.16	0.25KW	159rpm	15N.m	15.5kg	2330N	7.70
RF27DM71S4	7.63	0.25KW	170rpm	14N.m	15.5kg	2280N	8.00
RF27DM71S4	6.59	0.25KW	197rpm	12N.m	15.5kg	2180N	8.80
RF27DM71S4	5.60	0.25KW	232rpm	10N.m	15.5kg	2080N	9.60
RF27DM71S4	5.00	0.25KW	260rpm	9.2N.m	15.5kg	2000N	10.0
RF27DM71S4	4.27	0.25KW	304rpm	7.8N.m	15.5kg	1900N	11.0
RF27DM71S4	4.00	0.25KW	325rpm	7.3N.m	15.5kg	1870N	12.0
RF27DM71S4	3.37	0.25KW	386rpm	6.2N.m	15.5kg	1770N	13.0

RF27DT71S4減速機電機參數：

型號	減速比	功率	轉數	扭矩	重量	力矩	安全系數
RF27DT71S4	84.78	0.25KW	15.0rpm	156N.m	15.5kg	4100N	0.85
RF27DT71S4	74.11	0.25KW	18.0rpm	136N.m	15.5kg	4210N	0.95
RF27DT71S4	69.47	0.25KW	19.0rpm	128N.m	15.5kg	4240N	1.00
RF27DT71S4	61.30	0.25KW	21.0rpm	113N.m	15.5kg	4180N	1.15
RF27DT71S4	55.87	0.25KW	23.0rpm	103N.m	15.5kg	4090N	1.25
RF27DT71S4	48.17	0.25KW	27.0rpm	88N.m	15.5kg	3940N	1.45
RF27DT71S4	44.90	0.25KW	29.0rpm	82N.m	15.5kg	3870N	1.60
RF27DT71S4	39.25	0.25KW	33.0rpm	72N.m	15.5kg	3730N	1.80
RF27DT71S4	36.79	0.25KW	35.0rpm	68N.m	15.5kg	3660N	1.90
RF27DT71S4	32.47	0.25KW	40.0rpm	60N.m	15.5kg	3540N	2.20
RF27DT71S4	28.78	0.25KW	45.0rpm	53N.m	15.5kg	3420N	2.50
RF27DT71S4	24.47	0.25KW	53.0rpm	45N.m	15.5kg	3270N	2.90
RF27DT71S4	28.37	0.25KW	46.0rpm	52N.m	15.5kg	3410N	2.50
RF27DT71S4	26.09	0.25KW	50.0rpm	48N.m	15.5kg	3330N	2.70
RF27DT71S4	22.32	0.25KW	58.0rpm	41N.m	15.5kg	3180N	3.20
RF27DT71S4	19.35	0.25KW	67.0rpm	36N.m	15.5kg	3050N	3.70
RF27DT71S4	18.08	0.25KW	72.0rpm	33N.m	15.5kg	2990N	3.90
RF27DT71S4	15.63	0.25KW	83.0rpm	29N.m	15.5kg	2860N	4.50
RF27DT71S4	13.28	0.25KW	98.0rpm	24N.m	15.5kg	2730N	5.30
RF27DT71S4	11.86	0.25KW	110rpm	22N.m	15.5kg	2630N	5.90
RF27DT71S4	10.13	0.25KW	128rpm	19N.m	15.5kg	2510N	6.60
RF27DT71S4	9.41	0.25KW	138rpm	17N.m	15.5kg	2440N	7.00
RF27DT71S4	8.16	0.25KW	159rpm	15N.m	15.5kg	2330N	7.70
RF27DT71S4	7.63	0.25KW	170rpm	14N.m	15.5kg	2280N	8.00
RF27DT71S4	6.59	0.25KW	197rpm	12N.m	15.5kg	2180N	8.80
RF27DT71S4	5.60	0.25KW	232rpm	10N.m	15.5kg	2080N	9.60
RF27DT71S4	5.00	0.25KW	260rpm	9.2N.m	15.5kg	2000N	10.0
RF27DT71S4	4.27	0.25KW	304rpm	7.8N.m	15.5kg	1900N	11.0
RF27DT71S4	4.00	0.25KW	325rpm	7.3N.m	15.5kg	1870N	12.0
RF27DT71S4	3.37	0.25KW	386rpm	6.2N.m	15.5kg	1770N	13.0
